Non Asbestos Gaskets

• General Purpose Sheet Jointing & Gasket

General purpose gasket sheet, economical, composed of quality High quality inorganic fibres & NBR Binder for mild service in piping, OEM applications in hydrocarbons & refrigerants. Max Peak Temp: 280°C Pressure max: 40bar Max Cont. Temp: 150°C

• HIGHER GRADE SHEET JOINTING & GASKETS

Wide application gasket sheet produced with high grade Aramid Fiber & inorganic fibers blended with NBR binder. Best useful in process industries like pulp & paper, power, & petrochemicals. An excellent gasket for steam, mild caustics & acids in class 150 and 300 rating services. Exhibits good compressibility & recovery, seal-ability, flexibility & cutting characteristics. Max Peak Temp: 380°C Pressure max: 100bar Max Cont. Temp: 280°C

• SUPERIOR QUALITY SHEET JOINTING & GASKETS

High strength gasket sheet for severe applications throughout various industrial purposes like steam, natural gas, refrigerants, pulp & paper, food, beverage, pharmaceuticals,chemical, refinery & general industry. Composed of high strength Aramid & inorganic fibers-bonded with high quality NBR rubber. Max Peak Temp: 430°C Pressure max: 100bar Max Cont. Temp: 280°C

• TEMPERATURE RESISTANT SHEET JOINTING & GASKETS

High heated furnaces & molten bitumen are always a problematic area for gaskets designed to achieve long life sealing in heated joints & hot fluids. We blend Carbon Fiber with high grade NBR binder to attain special properties of industry needs. It is also produced with SS wire reinforced for higher tensile and strength. Max Peak  Temp : 450°C Pressure max: 150barMax Cont. Temp: 300°C
